Hydraulic tools · Busbar tools
Hydraulic busbar bender, 200 mm
A hydraulic bender for copper busbar up to 200 mm wide and 12 mm thick, with bending angles marked on the tool.
- Force
- 16.6 t
- Busbar width
- 200 mm
- Thickness
- 12 mm
We usually reply within 1–2 working days with price and delivery.
Used for
- Switchgear and panel making
- Electrical contractors
- Site busbar modifications
Features
- Robust and durable construction
- Single-acting, spring return
- Etched degrees for accurate bends
- Quick set-up on site
- Supplied with R2 3/8 male coupler and dust cap
- Runs from a 700 bar hand pump
Specifications
| Model | Output force (t) | Copper busbar breadth (mm) | Max thickness (mm) | Weight (kg) | Packed size (cm) |
|---|---|---|---|---|---|
| HLA-BB-20 | 16.6 | 200 | 12 | 27.7 | 28 × 31 × 38 |
No model matches. Clear the filter to see all models.
Horizontal busbar bender
| Model HLA-HBB-2 (horizontal type, 15 t cylinder) | Maximum bar size |
|---|---|
| Copper | 150 × 12.70 mm |
| Aluminium | 150 × 12.70 mm |
| Mild steel | 150 × 6.35 mm |
No model matches. Clear the filter to see all models.
Dimensions are as supplied by the manufacturer and may change. Ask us to confirm before you order.
How to order
- Choose the modelPick it from the table, or tell us the load, size and pressure and we suggest one.
- Send us the detailsThe model code from the table. Quantity. Where it will be used (so we can check it suits).
- We confirmYou get the price, stock position and delivery time, usually within 1–2 working days.
